Vehicle Exploded View - PIAGGIO VU PORTER ESSENCE/GPL/MÉTANE STANDARD 1000 Porter Multitech E6 Entry Level 2017-2019 PIAGGIO VU

Instalation du freins - transmisisons : 05.06 FREIN DE STATIONNEMENT
Frein de stationnement
Search
651928 - SENSOR

2
P2R reference P2R reference 111070
Maker reference Maker reference 651928

651928 - SENSOR

More information

Quantity required : 1

D9165160822 - BOULON

3
P2R reference P2R reference 110324
Maker reference Maker reference D9165160822

D9165160822 BOLT

More information

Quantity required : 2

COVER/PROTECTOR POUSSIERE BRAKE A MAIN OEM PIAGGIO PORTER 2010 > 2020-615091

4
P2R reference P2R reference 114681
Maker reference Maker reference 615091

COVER/PROTECTOR POUSSIERE BRAKE A MAIN OEM PIAGGIO PORTER 2010 > 2020-615091

More information

Quantity required : 1

261322 - ECROU

5
P2R reference P2R reference 109787
Maker reference Maker reference 261322

261322 NUT

More information

Quantity required : 2

NUT M6 OEM PIAGGIO COMMON A LA RANGE-D9411040600

6
P2R reference P2R reference 109797
Maker reference Maker reference D9411040600

NUT M6 OEM PIAGGIO COMMON A LA RANGE-D9411040600

More information

Quantity required : 2

CABLE/CONTROL/TRANSMISSION OF BRAKE A MAIN GRIP A REPARTITEUR OEM PIAGGIO PORTER-B000875

7
P2R reference P2R reference 116246
Maker reference Maker reference B000875

CABLE/CONTROL/TRANSMISSION OF BRAKE A MAIN GRIP A REPARTITEUR OEM PIAGGIO PORTER-B000875

More information

Quantity required : 1

9161160612000 - BOULON

8
P2R reference P2R reference 109933
Maker reference Maker reference 9161160612000

9161160612000 BOLT

More information

Quantity required : 1

B005030 - COLLIER

9
P2R reference P2R reference 113604
Maker reference Maker reference B005030

B005030 CLAMP

More information

Quantity required : 1

AGRAFE DE MAINTIENT CABLE OF BRAKE A MAIN OEM PIAGGIO PORTER 2020 <-9004465038000

10
P2R reference P2R reference 110441
Maker reference Maker reference 9004465038000

AGRAFE DE MAINTIENT CABLE OF BRAKE A MAIN OEM PIAGGIO PORTER 2020 <-9004465038000

More information

Quantity required : 3

9161160612000 - BOULON

11
P2R reference P2R reference 109933
Maker reference Maker reference 9161160612000

9161160612000 BOLT

More information

Quantity required : 2

644286 - COLLIER

12
P2R reference P2R reference 111801
Maker reference Maker reference 644286

644286 CLAMP

More information

Quantity required : 2

B005350 - SUPPORT

15
P2R reference P2R reference 115229
Maker reference Maker reference B005350

B005350 BRACKET

More information

Quantity required : 1

B005351 - SUPPORT

16
P2R reference P2R reference 115231
Maker reference Maker reference B005351

B005351 BRACKET

More information

Quantity required : 1

D9338116008 - VIS

17
P2R reference P2R reference 109936
Maker reference Maker reference D9338116008

D9338116008 SCREW

More information

Quantity required : 2

B000810 - CAOUTCHOUC

18
P2R reference P2R reference 112244
Maker reference Maker reference B000810

B000810 RUBBER

More information

Quantity required : 2

CABLE/CONTROL/TRANSMISSION OF BRAKE A MAIN REAR RIGHT OEM PIAGGIO PORTER MULTITECH STANDARD E4, E5, E6 2010 > 2020-1R000355

19
P2R reference P2R reference 158428
Maker reference Maker reference 1R000355

CABLE/CONTROL/TRANSMISSION OF BRAKE A MAIN REAR RIGHT OEM PIAGGIO PORTER MULTITECH STANDARD E4, E5, E6 2010 > 2020-1R000355

More information

Quantity required : 1

CABLE/CONTROL/TRANSMISSION OF BRAKE A MAIN REAR LEFT OEM PIAGGIO PORTER MULTITECH STANDARD E4, E5, E6 2010 > 2020-1R000354

20
P2R reference P2R reference 120029
Maker reference Maker reference 1R000354

CABLE/CONTROL/TRANSMISSION OF BRAKE A MAIN REAR LEFT OEM PIAGGIO PORTER MULTITECH STANDARD E4, E5, E6 2010 > 2020-1R000354

More information

Quantity required : 1
